1) Equipped with branded control system and multi-functional protection system, it offers higher level functional safety;
2) Equipped with vertical branded gear box, multi-functional solutions and flexible module construction system. Optimized gear meshing technology can reduce the noise and offer high performance and efficiency;
3) EPS steering energy reduces 20% with accurate operation, flexible steering, relieving operators pressures and greatly improving the production ability;
4) No need to adjust the buffering spring. It can adjust the vertical drive unit according to road conditions, increasing the steady operation efficiency;
5) High quality with buffering hydraulic system. Low noise, light shock, good seal, steady lift and lower processes;
6) Equipped with full AC drive system, small volume, light weight, high efficiency, free-maintenance and carbon-brush replacement. No more maintenance and protection;
6) Wide field mast design, specialized groove steel with high strength;
7) Customized electromagnetic or laser navigation AGV.
Characteristic
1.1
Model
CQDA10-25
CQDA15-25
CQDA20-25
1.2
Power(electricity,diesel,LPG,petrol,manual)
Electric
Electric
Electric
1.3
Operation(manual,walkie,side-standing,picker)
Rider type
Ridertype
Ridertype
1.4
Rated load capacity
Q(kg)
1000
1500
2000
1.5
Load center distance
C(mm)
500
500
500
1.6
The front overhang distance
X(mm)
155
155
155
1.7
Wheelbase
Y(mm)
1335
1435
1585
1.8
Forward moving distance
14(mm)
500
600
730
Weight
2.1
Service weight(incl.battery)
kg
1875
1900
2050
Wheel/ Chassis
3.1
Wheel type
PU
PU
PU
3.2
Drive wheelspecification
ø×w(mm)
φ230*75
φ230*75
φ230*75
3.3
Front wheel specification
ø×w(mm)
φ210*85
φ210*85
φ210*85
3.4
Rear Wheel specification
ø×w(mm)
φ150*50
φ150*50
φ150*50
3.5
Tread,front
b10(mm)
945
945
945
3.6
Tread,rear
b11(mm)
735
735
735
Dimensions
4.1
Vehicle height,mast retracted
h1(mm)
1845
1845
1845
4.2
Standard lifting height
h3(mm)
2500
2500
2500
4.3
Mast height,extended
h4(mm)
3470
3470
3470
4.4
Forks height,mast retracted
h13(mm)
35
35
40
4.5
Mast/forks tilting angle (the front/the rear)
a/β(°)
3/5
3/5
3/5
4.6
Vehiclebody length(excl/incl forks with pedal folded)
l1(mm)
1734/2276
1834/2276
1984/2346
4.7
Vehicle length(extra 536mm with pedal,without pedal)
