Equipped with branded control system and multi-functional protection system, it offers higher level functional safety;
Equipped with vertical branded gear box, multi-functional solutions and flexible module construction system.Optimized gear meshing technology can reduce the noise and offer high performance and efficiency.
Equipped with full AC drive system, small volume, light weight, high efficiency, free-maintenance and carbon-brush replacement. No more maintenance and protection.
Model
CBD20II
CBD25ⅢI
CBD30III
Power(electricity,diesel,LPG,petrol,manual)
Electric
Electric
Electric
Operation(manual,walkie,side-standing,picker)
Ridertype
Ridertype
Ridertype
Steering way
EPS
EPS
EPS
Rated load capacity
Q(kg)
2000
2500
3000
Load center distance
C(mm)
600
600
600
Wheelbase
Y(mm)
1380
1380
1380
Service weight(incl.battery)
kg
710
730
750
Wheeltype(The front/rear)
PU
PU
PU
Front wheelspecification
ø×w(mm)
φ80*80
φ80*80
φ80*80
The rearwheel specification
ø×w(mm)
φ230*75
φ230*75
φ230*75
Balance Wheel specification
ø×w(mm)
φ125*50
φ125*50
φ125*50
Mast height,extended
H(mm)
205
205
205
Forks surface height from the ground when lowering
Anhui Viwint Intelligent Technology Co.,Ltd.,a scientific and technological innovationenterprise focusing on the R&D,manufacturing and service of industrial vehicles,andits core business covers the R&D and production of electric forklifts,diesel forklifts,AGV automatic guided vehicles and narrow aisle three-way electric forklifts.With 1000customer service cases and export experience covering the Americas,Europe andother global markets,the company aims to build a leading brand in the field of logisticsequipment.
FAQ
Q:What is theMOQ? A: One set.
Q:Can I customize the equipment?
A:Yes, we offer customization service, including load capacity, lifting height, battery, color and others.
Q: Can I get spare parts or technical support after purchase? A: Yes, we provide lifetime support and spare parts supply. We can ship parts globally and assist via video call.
Q:How long is the warranty time? A: 12 months or 2000 hours whichever comes first.
Q:What is the payment terms? A: T/T, 30% pre-payment in advance, and 70% balance before delivery.
